Implantable Life Support – HRC5000 TAZ Series

HRC5000 TAZ Series
Features & Benefits
  • Capacitance ranging from 0.1μF to 300μF
  • Voltage range from 4V to 50V
  • Recommended for medical implantable life support designs
Typical Applications
  • Medical Implantable Applications

The TAZ HRC5000 Medical Grade series is designed for use in medical implantable applications. These are based off of the MIL-PRF-55365 case sizes and feature extremely low DC leakage levels well below typical values. These components are manufactured and tested in the AVX Biddeford Maine factory which is ISO 13485 certified. Weibull grading and surge current testing options per MIL-PRF-55365 are available along with several plating options including tin/lead solder, 100% tin, or gold terminations.
