SRC9000 – TBM Multianode

TBM Series
Features & Benefits
  • Capacitance ranging from 22µF to 1500µF
  • Voltage range from 2.5V to 35V
  • Incorporates extensive space level testing
Typical Applications
  • Satellites
  • Space exploration vehicles

The TBM COTS-Plus Space level series uses an internal multi-anode design to achieve ultra-low ESR for use in space level applications. These components come standard with Weibull reliability level “C” and surge current option “C” per MIL-PRF-55365 Rev. G. For details on the SRC9000 or T-level specification please contact the factory.
