24-9159-100 Series | Two-Piece IDC – Socket

24-9159-100 Series | Two-Piece IDC – Socket

The IDC cable socket connector allows for 22-24AWG discrete or cabled wires to be easily and reliability terminated into a 9159 standard interface plug connector. This will allow power and signals to be connectors onto a PCB socket connector while providing positive latching. The wire assembly support block allows for 2 through 6 wires to be terminated all in one step with any standard bench top press. IDC covers provide both through (daisy chain applications) and wire stop termination options.

For more information about KYOCERA AVX Connectors, visit our connector portfolio or contact our technical support team.

• Mates with standard 9159 horizontal plug, keeping same BTB connector system
• Economical and reliable IDC wire termination
• Gold plated BeCu contact system for high reliability in harsh environments
• Integrally molded latch offers positive latching after mating

• Provides Wire-to-Board capabilities to standard 9159 2-Piece connector system
• In conjunction with the IDC plug WTB connector (14-9159), these connectors provide maximum flexibility to bring power and signal wires onto or off of any board level 9159 connector

• AVX Interconnect – Series 9159 Cabled Plug and Socket
