9296-11X Series | Poke-Home Vertical Contact Thru-Board Wire Insertion (12-18 AWG)

9296-11X Series | Poke-Home Vertical Contact Thru-Board Wire Insertion (12-18 AWG)

KYOCERA AVX continues to develop unique connectors to fill the gap in the market. The newest addition to KYOCERA AVX’s broadening line of wire to board poke-home is the 12-18AWG box contact 9296-11X, which is extension of popular vertical poke-home contact 70-9296. This new box contact will allow all 12-18 AWG solid wires and stranded wires. All wire types can be used in both plated and un-plated condition.

This small contact is packed with several key features that provide significant functionality in a broad range of applications. The contact is designed for PCB surface mount and termination is accomplished with 12-18AWG wires pushed directly into the contact.

For more information about KYOCERA AVX Connectors, visit our connector portfolio or contact our technical support team.

• Maximum 20 Amps current rating meets robust application requirements
• Accepts 12-18 AWG solid and stranded wires
• Box contact with side walls provides maximum mechanical stability & wire retention
• Tape and reel packaged for automated SMT placement
• UL approved

• Machine Controls: motors, drives, solenoids, sensors, battery packs, fans and pumps
• Commercial Buildings: controls, security, fire and sensors
• SSL/LED: Fixtures, signage and street lights
• Home appliance: Vacuums and floor cares, washing machines, dryers
