9155-250 Series | Battery Connector – Reduced 2.5mm Pitch

9155-250 Series | Battery Connector – Reduced 2.5mm Pitch

The 9155-250 has a nominal working height of 4.5mm compared with the existing 9155-200 which has a nominal working height of 3mm. These connectors are rated at a full 3 Amps per contact on 2.5mm centers. This series includes 2 through 5 position connectors that are end to end stackable.

The complete family of connectors 9155 series offer all the same advantages: Ultra reliable and robust gold plated beryllium copper contacts provide high integrity connections in harsh environments, with 5000 mating operations, high temperature nylon plastic for RoHS soldering. Additionally, 9155-250 is made from halogen free nylon.

For more information about KYOCERA AVX Connectors, visit our connector portfolio or contact our technical support team.

• 3.6mm insulator height
• 3 amps/contact
• Large SMT mounting area for positive mechanical attachment
• 5,000 mating cycles
• End-to-end stackable

• Handheld/portable devices requiring docking or cradle charging
• Patient monitoring or portable medical electronics
• Industrial devices requiring pluggable or programming modules
• Internet appliances requiring battery back-up
