9286-200 Series | Reduced Thru Wire Connector 18-24 AWG

9286-200 Series | Reduced Thru Wire Connector 18-24 AWG

The reduced 9286-200 series of thru wire connectors expands on the already proven 9286 poke-home discrete WTW family of connectors, but in a smaller package size. The development of an active stainless steel spring contact eliminates the need for push button activation to insert and remove wires which offers a significant cost savings. The mechanical properties of this contact provide maximum wire retention across a broad range of solid and stranded wire gauges, making this connector very versatile in field installations.

For more information about KYOCERA AVX Connectors, visit our connector portfolio or contact our technical support team.

• Simple strip and poke-home wire insertion with twist and pull wire extraction
• High spring force stainless steel contact maximizes cost, strength, and flexibility
• Accepts 18-24 AWG solid and stranded wires
• Expanded size offering to cover multiple power and signal applications: 1p-6p

• Industrial/Machine Control; motors, solenoids, sensors, fans, pumps, etc.
• Commercial Buildings; controls, security, fire, and sensors
• Smart Grid; meters, breakers, and panels
• SSL/LED; fixtures, signage, and streetlights
