Standard Ceramic Capacitors (MLCC) with FLEXITERM® | KGF Series


Features & Benefits
  • Voltage: up to 200Vdc
  • Capacitance Range:
    270pF up to 22uF (2220, 25V, X7R)
  • Dielectric: X7R or X8R
Typical Applications
  • High Flexure Stress Circuit Boards
  • Soft termination offers improved reliability performance in applications where there is temperature variation.
  • All kind of engine sensors: Direct connection to battery rail

FLEXITERM® is designed to enhance the mechanical flexure and temperature cycling performance. The FLEXITERM® layer protects the component from any damage to the ceramic resulting from mechanical stress during PCB assembly or use with end customers. Using FLEXITERM®, KYOCERA AVX provides up to 5mm of flexure without internal cracks. Beyond 5mm, capacitor will generally fail “open”. Temperature cycling performance is increased to 3000 cycles and beyond.
