6809 Series | 0.5mm Pitch

Features & Benefits

Design structure prevents breakage
Contact Material: Copper alloy
Insulator Material: Heat-resistant plastic
Operating Temperature Range: -40 to +85°C

The 6809 Series possess enhanced robustness after implementing measures aimed at reducing breakage of connectors caused by human error. These low profile products feature a pitch of 0.5mm, bottom contact, front-lock type with a height of 0.93mm for mounting area, and can be applied to FPC/FFC thicknesses of 0.3mm.
